FLS BRONZE Forward Looking Sonar

Performance?

Both work well. With its smaller face, thestandard transducer offers slightly less drag and sometimes less turbulence. The professional transducer with its larger crystals has a narrower beam giving slightly greater range and better definition, (however compared side by side the standard picture often looks better as it’s like painting with a broad paint brush). Both are designed to shear off if hit really hard by an underwater obstruction without affecting thewater tight integrity of the hull.One final thing - remember you can not use twosounders or sonar at the same frequency on the same boat (or near another boat sometimes). One will transmit, the other will pick up its echo from the sea bed and both will be confused.All EchoPilot vertical sounders run at 150KHz.All EchoPilot Forward looking sonars 200KHz so they work well together. Brookes and Gatehouse use 183KHz (again compatible) butRaytheon use 200KHz so are not.It is essential to fit a switch to disable any othersounder without an on/off switch working at 200KHZ. And when using the other sounder switch the EchoPilot sonar off!If you need any more help or advice phone or E-mail our factory or one of our distributors or dealers - we are here to help you.

Technical specificationDimensions Transducers

Voltage Consumption Frequency

Professional Standard

12 150ma Max 200 KHz

77 mm usable thread 146 mm 110 mm 21 mm Hole Size: 60 mmDiameter
37 mm 51 mm
110 mm 74 mm 26 mm usable thread29 mm 83 mm 33 mm

Standard Kit

Hole Size: 45 mm

DisplayMounting kit Transducer (standard) or Transducer (professional) Thru-hull fittings & blanking cap Shipping weight:FLS Bronze Standard2.0Kg approx.FLS Bronze Professional4.0kg approx.

33 mmDiameter

EchoPilot have a policy of continuous improvement and reserve the right to change specification
