KTA50-D[M1]
Marine Generator Drive General Specifications
Configuration V-16 cylinder, 4-stroke diesel Aspiration Turbocharged/Aftercooled Displacement 50 liters3068 in
3 Bore & Stroke 159x159 mm6.25x6.25 in Compression Ratio 13.9-14.5:1 Rotation Counterclockwise facingflywheel
Ratings
Prime Power @ 50 Hz (1500 RPM)
Output PowerFuel Cons**Emissions
kWBHPkWe*L/hrGal/hr 10071350967109.729IMO 109714701053117.130.9IMO Prime Power @ 60 Hz (1800 RPM)
Output PowerFuel Cons**Emissions
kWBHPkWe*L/hrGal/hr 11411530109612333.2IMO 129117301239139.336.8IMO *kWe reflects the approximate amount of power available when used in a keel cooled genset configuration**Average fuel consumption at ISO 8178 D2 standard test cycle Length mm (in)2603(102)KC Width mm (in)1564(62) Height mm (in)2252(89) Weight kg (lb)5431(11973) Dimensions may vary based on selected engine configuration 43
