QSK19-M

Main Propulsion General Specifications

Configuration In-line, 6 cylinder, 4-stroke diesel Aspiration Turbocharged/Aftercooled Displacement 19 liters1150 in

3

Bore & Stroke 159x159 mm6.25x6.25 in Compression Ratio 15.0:1 Rotation Counterclockwise facingflywheel

Commercial Ratings

kWBHPRPMFuel Cons*RatingEmissions L/hrGal/hr 49266018008422CONIMO 56776021009726HDIMO 597800210010227MCDIMO
*Average fuel consumption at ISO 8178 E3 standard test cycle

General Engine for boat Dimensions

Length mm (in)1692(67)KC Width mm (in)1011(40) Height mm (in)1650(65) Weight kg (lb)2373(5231) mm (in)1950(77)KC Overall Length 2070(82)HX
Dimensions may vary based on selected engine configuration
