by
INDUSTRIAL INC
#1 Quebec Drive, RR#2 Parry Sound, ON P2A 2W8 Tel 888-480-3777 Fax 705-378-5068 Email sales@con-o-lift.com Overall trailer length - 45' 4"Usable bed length - 35'
Overall trailer width - 8' 6" (custom width frames also available) Frame size - 12" x 12" x .500" HSS steel tube
Capacity (size) -
Powerboats to 45' LOA -
Sailboats to 47' LOA
Capacity (weight) - 40,000 lbs highway
- 50,000 lbs off-road
Air braking system with ABS (12-1/2" x 7-1/4" brakes) with remote control operation
Trailer Dimensions:
HDfifth-wheel gooseneck with lockable aluminum storage boxesKeel ride height - 16"Clear width between frame rails - 32" Two year warranty on frame and hydraulic components with 90 days limited warranty on lights, brakes, and running gear
Two - 22,500 lb Dexter axles with Firestone air-ride
Complete hot dip galvanized frame including hubs, brake drums, and rimsHydraulic-poweredfront landing wheelsPilot operated safety lock valves on hydraulic armsSeven 6" x 6" oak crossbeams
Wireless remote control for all functions including main lift, hydraulic arms, and brakesManual back-up control panel on trailer for all functions (secured in lockable cabinet) Air powered frame lift (lift range is from 13" - 21" over crossbeams)Six hydraulic arms featuring manual telescopic extension / rear arms rotate fore and aft
Stainless steel hydraulic fittings including cylinder shaftsStainless steel hardware package includes stainless steel pivot shafts and oilite bronze bushings Pressure-fed oil-filled hubsTires: 235/75R17.5 radials - load range "J" - 9 rims & tires total (including spare)MTO/DOT approved lighting package - LED lightsRubberfenders
Con-o-lift reserves the right to change specifications or substitute components as requiredin an effort to supply a better product in an ever changingmarketplace.
