| | | ÇJ/SAILBATTENS | | |
| | | NALR | | |
| | | |
| | | |
| | | Non-Adjusting The Non-adjusting Acetyl Luff Receptacle is a tough, simple and durable batten receptacle. Acetyl It attaches to one side of the sail with a plastic backing plate fixed with lock-nuts. Luff Receptacle The NALR is ideal for use when a light-weight receptacle is required with minimal batten adjustment. These highly durable receptacles have been around the world on ABN AMRO 1 and 2 and Team Ericsson in the Volvo Ocean Race. | | |
| | | |
| | | Batten Range/ Yacht Size | | |
| | | Battens suitable for NALR Receptacles i CT22 à CT33 à CT33S | | à Yachts 18ft-90ft | | |
| | | |
| | | |
| | | |
| | | Key Features | | |
| | | i Outer shells made from carbon fibre i Made from tough acetyl plastic A Lightweight and strong i Used with open leech batten pockets k Batten is tensioned by flap or lashing system at leech Similar CT Sailbatten Receptacles | | |
| | | J Attaches through sail with stainless steel bolts; nylock nuts are used on the 2 bolts taking most load i Manufactured to fit stud threads as_____ follows: - M10 Metric Coarse thread - M-12 Metric Coarse thread - M-14 Metric Coarse thread | | |
| | | |
| | | |
| | | Similar Receptacles | | |
| | | |
| | | AALR: Adjusting Aluminium Luff Receptacle | | |
| | | |
| | | |
| | | ACLR: Adjusting Carbon Luff Receptacle | | |
| | | |
| | | APLR: Adjusting Plastic Luff Receptacle | | |
| | | |
| | | NPLR: Non-adjusting Plastic Luff Receptacle | | |
| | | |
| | | | | | | | | | | | | | | | | Product | Fits | Yacht | Stud | Length | Width | Thickness | Weight | Batten Size | | | | Name | with | size | Size | A | B | C | (grams) | Accepted | | | | | | (ft) | (mm) | (mm) | (mm) | (mm) | | (mm) | | | | NALR22 | CT22 | 18-50 | 10 -12 | 110 | 50 | 22 | 155 | 25 x 14 | | | | | | | | | | | | | | | | |
| | | Size Guide | | |
| | | |
| | | |
| | | NALR33 CT33 | | |
| | | 60 - 90 | | |
| | | 12-14 | | 140 | | 66 | | 30 | | 385 | | 36 x 18 | | |
| | | |
| | | |
| | | |
| | | Optional M10 M12 M14 M6 Threads | | |
| | | |
| | | Thickness C | | |
| | | |
| | | Section A-A | | |
| | | |
