| | | ÇJ/SAILBATTENS | | |
| | | CCLR | | |
| | | |
| | | |
| | | Carbon The Carbon Clam-shell Luff Receptacle has been designed specifically for use with a bolt rope Clam-shell mainsail. A soft plastic insert, trimmed to match the luff angle, fits inside the batten pocket. The bolt Luff Receptacle rope for boat is sewn in place onto the plastic insert and sail. Tough outer shells made of carbon fibre fit on either side of the sail to hold the batten in place. Although the CCLR is intended for use with CT22 battens it can also be used with similar sized fibreglass and pultruded battens. The CCLR is available in both non-adjusting (CCLR) and adjusting (CCLR-A) formats. | | |
| | | |
| | | Batten Range/ Yacht Size | | |
| | | Battens suitable for the CCLR i CT22 | | |
| | | | | |
| | | |
| | | |
| | | |
| | | Key Features | | |
| | | i Outer shells made from carbon fibre k Bolt-rope can be sewn onto plastic insert i Can be set up very close to bolt-rope without track damage i Receptacle sits on centre-line of sail i Attached through sail with stainless or titanium bolts and nylock nuts Similar CT Sailbatten Receptacles | | |
| | | No corrosion on carbon sail (also available with titanium bolts) 1 CCLR-A has an adjustment knob for tensioning batten (maximum adjustment: 25mm) I Weight of CCLR: 80 grams Weight of CCLR-A: 105 grams | | |
| | | |
| | | |
| | | Similar Receptacles | | |
| | | |
| | | |
| | | APLR: Adjusting Plastic Luff Receptacle | | |
| | | |
| | | NALR: Non adjusting Acetyl Luff Receptacle | | |
| | | |
| | | 18mm of extra material for shaping and sewing or hand working to the sail if necessary - 108 - | | |
| | | M5 Screws x 4 with nylock nuts | | |
| | | |
| | | |
| | | 85mm Width of batten pocket | | |
| | | |
| | | 11mm betweer internal pocket and edge of plastic | | |
| | | |
| | | 2.5mm of deflection each side for pocket to go around plastic | | |
| | | |
| | | Extra plastic material so it can be cut to suit the angle | | |
| | | |
| | | © Copyright C-Tech Ltd. | | |
| | | |
| | | CT Sailbattens Manufactured by: C-Tech Ltd PO Box 58, Waitakere 0660, Auckland, NEW ZEALAND | | Phone: +64-9-810-8406 +64-9-810-8409 www.sailbattens.com info@sailbattens.com | | |
| | | |
| | | AlexVallings (Director) Mobile: +64-21-671-118 Fraser Brown (European Sales) Mobile: +44 (7816) 550 923 | | |
| | | |
| | | |
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
