A C T I S E N S E D A T A S H E E T www.actisense.com sales@actisense.com +44 (0)1202 746682 ® NMEA 2000 Micro Power-T Technical Specifications Electrical Rated Current 4A Rated Voltage 25 V (AC/DC) Mechanical Male Contact Brass, gold plated Female Contact Phosphor bronze, gold plated Contact Carrier PBT, black Contact Polarisation Standard M12 -“A”- polarisation Mating Thread M12 Screw Cap Brass, nickel plated O-Ring Seal Rubber, black Housing PVC, black Cable Jacket Material 0.8 mm Nom. PVC, black Cable Outer Diameter 6.85 mm ±0.254 mm Cable Length 3M Wire Length 100 mm (mm stripped) Wire Jacket PVC Wires 18 AWG (stripped and tinned) Drain 18 AWG (34 strand tinned copper) Shield Al-mylar Weight g Approvals and Certifications Protection IP67 (when mated) Operating Temperature -20°C to +70°C Storage Temperature -40°C to +85°C NMEA 2000 Certified RoHS Compliant UL Certified (E137250, UL1277) Connections Name Connector Colour Power Ground Shield Power Ground Male Male Male & Female Female Female Solid Red Solid Black Bare Red/White Stripe Black/White Stripe Part Number A2K-MPT-1 Description NMEA 2000 Micro Power-T Issue 1.00
